MACHINES

.

MULTITASKING DEPARTMENT

• MAZAK INTEGREX I-300ST multitasking turning-milling center
5 axis, 400mm turning diameter, 12 stations lower tower, a selection of 70 tools, automatic loader passage bar diameter 80mm. With Robot Fanuc M20ia-20M robotic ARM.

• MAZAK INTEGREX I-200H-ST multitasking turning-milling center

• MAZAK INTEGREX 200-2SY5 multitasking turning-milling center
5 axis, 300mm turning diameter, 12 stations lower tower, a selection of 112 tools. With GL150 robotic loading and unloading system and an automated loader that can process bars up to 52mm in diameter.

.

TURNING DEPARTMENT

• MURATEC MT200 GT3 twin-spindle turning machine
3 motorized turrets, 2 C-axes, 3 Y-axes, 70 mm diameter bar passage automatic loader and gantry loading system with robotic arm.

• BIGLIA 436 Y2 twin-spindle turning center
2 motorized turrets, 2 C axes, 2 Y axes, automatic bar loader 36 mm diameter, tailstock on counter spindle and high-pressure cooling system.

• BIGLIA 438 Y2 twin-spindle turning center
2 motorized turrets, 2 C axes, 2 Y axes, automatic bar loader 38 mm diameter, tailstock on counter spindle and high-pressure cooling system.

• BIGLIA BMX45 Y2 twin-spindle turning center
 motorized turrets, 2 C axes, 2 Y axes, automatic bar loader 45 mm diameter, tailstock on counter spindle and high-pressure cooling system.

• BIGLIA 465 Y2 twin-spindle turning center
2 motorized turrets, 2 C axes, 2 Y axes, automatic bar feeder diameter 65 mm.

• BIGLIA 465 T2 Y2 twin-spindle turning center
2 motorized turrets, 2 C axes, 2 Y axes, automatic loader, bar passage diameter 70 mm.

• BIGLIA 545 YS twin-spindle turning center
Motorized turret, C axis, Y axis, 51 mm diameter bar passage automatic loader.

• MORI SEIKI NL2500 SY / 700 twin-spindle turning center
Motorized turret, C axis, Y axis, 400 mm turning diameter, 80 mm diameter bar passage automatic loader.

• MENTI twin-spindle turning center
2 motorized turrets, 2 C axes, 2 Y axes, turning diameter 400 mm, automatic bar feeder with 80 mm diameter.

• BIGLIA 131 / S single-spindle CNC lathe
2 axes, automatic bar feeder diameter 65 mm.

• MORI SEIKI SL15 single-spindle CNC lathe
2 axes, turning diameter 200 mm.

• MORI SEIKI CL20 single-spindle CNC lathe
2 axes, turning diameter 320 mm.

• MORI SEIKI CL153 single-spindle CNC lathe
2 axes, 14-station gantry loader, 160 mm turning diameter.

.

MILLING DEPARTMENT

• MAZAK HCN-5000 horizontal machining center
4 continuous axes, 160 tools, Palletech High Rise System (500N)

• MORI SEIKI NHX5000 horizontal machining center
4 axes in continuous, 2 pallets, M730BM daisy change system with 5 pallets complete with setup station.

• MAZAK FH4800 horizontal machining centers
4 axes, 2 pallets.

• SERRTECH M4 vertical machining centers
5 axes.

• EMCO MILL E600 vertical machining center With CNC table
4 axes.

.

QUALITY CONTROL

• DEA GLOBAL S 07.10.05 automated 3D measuring machine
Measuring strokes (mm): x=700, y=1000, z=500

• Three-dimensional coordinate measuring machine MITUTOYO CRYSTA APEX C
Accuracy 1.7 μm.

• VICIVISION M309 TECHNO optical measuring machine
Optical measuring machine for the external dimensional monitoring of cylindric elements. Measurements are taken with an optical no-touch system.

.

DRILLING

• Robotic island for drilling COMAU C3G PLUS flame-spreader
SMART MILL anthropomorphic robot with 6 axes + 2 external axes.

• Pneumatic drilling machines C MECCANICA
4/5 drilling heads, electric motor, CNC rotary table and automatic loading.

.

CUTTING

• WHITE CNC sawing machine MOD 360
Cutting capacity up to 360 mm.

• WHITE MOD 370 CNC sawing machine
Cutting capacity up to 370 mm.

.

WASHING

• IFP KP 100 BASIC washing plant
Fully vacuum-packed, automatic loader.
